How to install a 300mm base cabinet

A person attaching a base plate for an adjustable foot underneath a cabinet

Overview

Flat pack kitchen cabinets are an affordable way to renovate a kitchen. We'll teach you how to put together a 300mm base cabinet yourself. You'll see how to screw the panels together and install the plastic feet on the base.

Steps

1Attach the sides of the 300mm base cabinet to the base panel

Put the first side panel into place and line up the pre-drilled holes. Use an impact driver to gently drive the screws into place. When the first side is on, turn the cabinet over and do the same on the other side. Check to see if the joining edges have properly lined up. If not, tap them lightly into place with a rubber mallet and then tighten the screws.
Person attaching base panel of cabinet

2Attach the back to the 300mm base cabinet

Put the back panel into place and line up the pre-drilled holes. Screw the back and both side panels together, then turn the cabinet upside down and do the base panel. Once again, check your edges are properly lined up and use the rubber mallet to tap them into place before you give your screws a final tighten.
Person attaching panel of cabinet using drill

3Attach the top rail to the 300mm base cabinet

Put the top rail into position. Push all four screws into place with your thumb to temporarily hold the rail in place. Then drive the screws in and use the rubber mallet again to tap the edges into place before giving the screws a final tighten.
Person attaching cabinet rail using a drill

4Attach the plastic feet to the bottom of the kitchen cabinet

The plastic feet for your kitchen cabinets come in four parts – base plate, tube, screw thread and foot. Attach the base plate to the base of the cabinet, using the pre-drilled holes and the short screws. Push the tubes into the base plates and the feet onto the screw threads. Then drive the screw threads into the tubes.
Person attaching plastic feet to cabinet using a drill

5Adjust the height of the feet

You can adjust the height of your feet by screwing the threads in or out. This is very useful if your floor isn't level. Use a combination square to help set the height of all the feet at 145mm. Then put the cabinet in place and adjust the feet if you need to level it up on an uneven floor.
Person adjusting cabinet feet height
